Regular price Save $-379.99
/

Only 2 items in stock!
  • A high-performance alloy rim designed for freeride, enduro and downhill race use
  • Tubeless-ready with anti-burp rim hooks to prevent the loss of pressure and keep tires firmly in place
  • 32 holes with an inner width of 28mm and outer width of 33mm to optimize tire spread and enhance traction
  • The corrugated rim center adds exceptional strength, making it more rigid and allowing the rim to be wider without adding material
  • Shot peen finish to increase fatigue life and make it more durable
FRONT WHEELS TO PAIR WITH:
SPIKE RACE 33




VARIANT SPECS

(Available factory standard in XD and Shimano HG.  Micro spine freehubs available).


HUB HUB SPACING BOOST FREEHUB HOLE COUNT ADAPTER INCL. WEIGHT ERD ETRTO SPOKE LENGTH SPOKE LENGTH
26"
HEX J TYPE
12x142 - HG 32H 12x135 997g 529++ 559x28 R-255 L-258
HEX J TYPE
12x142
- XD 32H 12x135 989g
529++
559x28
R-255
L-258
HEX J TYPE
12x150 - HG 32H 12x157 1008g
529++
559x28
R-255
L-258
HEX J TYPE
12x150 - XD 32H 12x157 1000g
529++
559x28
R-255
L-258
S/S BOLT ON 10x135 - 11T 32H - 1124g
529++
559x28
R-255
L-258
27.5"
HEX J TYPE
12x142
- HG
32H
12x135 1038g 554++ 584x28 R-266 L-269
HEX J TYPE
12x142
- XD
32H
12x135
1030g
554++
584x28
R-266
L-269
HEX J TYPE
12x150 - HG
32H
12x157 1049g
554++
584x28
R-266
L-269
HEX J TYPE
12x150
- XD
32H
12x157
1041g
554++
584x28
R-266
L-269
HEX J TYPE
12x148 BOOST HG
32H
- 1044g
554++
584x28
R-266
L-269
HEX J TYPE
12x148 BOOST XD
32H
- 1036g
554++
584x28
R-266
L-269
29"
HEX J TYPE
12x150 - HG
32H
12x157 1086g 591++ 622x28 R-285 L-288
HEX J TYPE
12x150
- XD
32H
12x157 1078g
591++
622x28
R-285
L-288
HEX J TYPE
12x148
BOOST
HG
32H
- 1081g
591++
622x28
R-285
L-288
HEX J TYPE
12x148
BOOST
XD
32H
- 1073g
591++
622x28
R-285
L-288

COMPATIBLE REAR ADAPTERS

Boost R148:

HEX Rear Hub QRx135/141 Adapter

R150/157:

N/A

R135/142:

HEX Rear Hub QRx135/141 Adapter


HEX Rear Hub 10x135 Adapter


COMPATIBLE SERVICE KITS

HEX Rear HG/HGR Hub Replacement Bearing Kit

HEX Rear XD/XDR Hub Replacement Bearing Kit

HEX Boost Rear Hub Alloy Axle Shaft

HEX Rear Hub 135/142mm Alloy Axle Shaft

HEX Rear Hub 150/157mm Alloy Axle Shaft

HEX Rear Hub HG Alloy Anti-Bite Freehub

 HEX Rear Hub XD Alloy Freehub


CLASSIFICATION & INTENDED USE:
  ASTM 5

ALL MOUNTAIN
TRAIL
ENDURO
FREERIDE
-
DOWNHILL GRAVEL XC E-BIKE
- - *

 * Recommended for E-Bike when adapting with SPANK HEX DRIVE steel freehub (available as a separate purchase in HG, XD, and Microspline.  (See Hex Drive Service Parts)

HUMAN FACTOR

SPANK's recommendations for what body type and ride style this product is suited to.

BODY WEIGHT & RIDE STYLE: Heavy Rider Medium Rider Light Rider
Heavy Impact

Medium Impact

Light impact

RIM SPECIFICATIONS
HOLE COUNT:
32
INNER WIDTH (mm):
28
OUTER WIDTH (mm):
33
PROFILE HEIGHT:
22
TYRE FIT
1.9" to 2.5"

BUILD SPECIFICATIONS
BUILD:
Handbuilt
HUB: SPANK HEX J-TYPE
SPOKES:
J-Hook, tripple butted 2.2/1.8/2.0
NIPPLES:
Brass external
LACING:
3 cross lacing
VALVE: F/V Presta
TUBELESS: Tubeless taped & valved

HUB SPECIFICATIONS:

ENGAGEMENT:
HEX DRIVE 102T / 3.5° / 6 Pawl
HOLE COUNT:
32H J-Hook
DISC MOUNT:
6-bolt
MATERIAL:
CNC optimized forged alloy hub body, alloy axle, alloy freehub body

FREEHUB COMPATIBILITY – What freehub do I need?
